Schnedier Electrical Elements Floor Grinder Polisher With Redi Lock
Diamond Grinding Tool
HW-G1 is a floor grinder as well as an edge grinder. It is light
and compact, very easy to transport and comfortable to operate.
Triangle structure stablize motor and grinding plate. Safe and
reliable and in accordance with human ergonomics.
Parameters
| Model | HW-G1 |
| Voltage: | 220V 1phrase |
| Power output: | 2.2KW,3hp |
| Motor Brand: | China Winder |
| Frequency: | 50/60HZ |
| Current: | 13A |
| Grinding Width: | 280mm/11” |
| Grinding Pressure: | 41KG/90.2lbs |
| Additional Weight: | N/A |
| Dust Port: | Φ50mm |
| Motor Speed: | 1400rmp |
| Diamond Pad Holder: | 6 Pieces |
| Machine L*W*H: | 1100*420*1000mm |
| Net Weight: | 75KG/165lbs |
Features
1, ‘Schneider’ and ‘Delixi’ apparatus guarantee electrical safety ;
2, Robust Stamping part makes sure of the machine’s stability;
3, Self floating cover follows floor's ups and downs, to prevent
dust;
4, Vacuum cleaner can be connected.
5, Almost no need for machine maintenance.
Closer Look
Comparison
After Sell Service
- One year of warranty for machine.
- In the warranty period, the spare parts are sent by DHL, which is
paid by Honway Company.
- Out of warranty period, the spare parts are sent by DHL, which is
paid by customer.
- Honway always store the spare parts of old models, in case that the
machine needs repair in future.
- All gear boxes are tested 48 hours before it leaves factory.
- We could send the technologists to distributors, for training the
after sell service staff and maintenance issues.
FAQ
Q: If the floor edge grinder could grind floor?
A: Yes, it can; its grinding width is 280mm and its grinding pressure
is 90.2 lbs;
Q: If HW-G1 could grind floor edge and leaves no margin at all?
A: G1 could grind floor edge, but leaves margin of 2mm, which is the
narrowest margin which the floor edge grinder could achieve. It is
impossible for any machine to leave margin 0mm.
Q: If HW-G1 could grind right edge and left edge?
A: Yes. It can; the two sides could grind floor edge;
Q: How about the floating cover of HW-G1?
A: The floating cover follow floor up and down, preventing dust from
entering work site.
