Four Pieces of Grinding Plates 230mm Floor Grinding And Polishing
Machine with Delta Inverter WEG Motor
HW-G10 is 650mm, motor 10hp, we can custom 220V or 380V to meet your working need.
Planetary gear box, automatic pressure adjustable system and 4
heads can make your work more 30%-40% efficient than other type,
the labor cost will be saved a lot.
Application:
Levels uneven concrete surfaces and removes paint, traffic lines,
fibreglass, expoxy and adhesives.
Smoothing or flattening concrete slabs–including curled expansion
joints.
Parameters
| Voltage | 220-240V ,1P/3phrase | 380V-440V, 3phrase |
| Frequency | 50/60HZ | 50/60HZ |
| Current | 26.7A | 15.5A |
| Power Output | 10hp(7.5KW) | 10hp(7.5KW) |
| Inverter power | 15hp(11KW) | 15hp(11KW) |
| Motor speed | 300-1800rpm | 300-1800rpm |
| Grinding width | 650mm | 650mm |
| Disc Dianeter | 250mm*4plate | 250mm*4plate |
| N.W | 270KG | 270KG |
| Water Tank | 30L | 30L |
| Dimension | 970*650*950mm | 970*650*950mm |
Features
1, Gear box and motor are made of aluminum that brings long lifespan, steadiness and durability.
2, Separable design of the gear box and add weight iron that it is
easy to move.
3, The floor grinder handle can be rotated by 360 degrees to adjust
to fit each operate comfortably.
4, High quality engine to ensure the power strong.
Product Details
1, Integrated control panel is easy to control and process. (you could call it " foolish operation")
The panel has: inverter screen, indicator lights, switches, motor
direction switches.
2, The direction of bottom disk can be clockwise or anticlockwise.
To prevent uneven wear of the grinding disc and efficiently achieve
a smooth grinding surface.
Closer Look
Production Flow
Company introduction
Changsha Honway Machinery Co., Ltd is the Professional manufacturer
for floor scarifying & grinding & polishing machine in China. Our
company is well equipped with CNC machine for mechanical treatment
and gear hobbing machines for gear processing. We are proud of
having a team of experienced technicians and workers. All of the
products are CE certified and comply with international standard.
The products are already exported to 20 countries and got the good
reputation.
After Sell Service
- One year of warranty for machine.
- In the warranty period, the spare parts are sent by DHL, which is
paid by Honway Company.
- Out of warranty period, the spare parts are sent by DHL, which is
paid by customer.
- Honway always store the spare parts of old models, in case that the
machine needs repair in future.
- All gear boxes are tested 48 hours before it leaves factory.
- We could send the technologists to distributors, for training the
after sell service staff and maintenance issues.
FAQ
Q: If you are a trader company or the real manufacturer?
A: Honway is a real manufacturer. It is located in Changsha, Hunan
province. Welcome you come to our factory and produce process at
any time.
Q: What is your MOQ?
A: 1 set
Q: What is your packaging?
A: We package in Plywood case.
Q: What is your main market?
A: USA, Australia, Asia
