Almost all kinds of floor: concrete, terrazzo, marble granite
floor, etc.
For concrete coarse grinding, medium grinding, fine polishing,
crystallizing, preparation
Parameters:
| Voltage | 220-240V ,1P/3phrase | 380V-440V, 3phrase |
| Frequency | 50/60HZ | 50/60HZ |
| Current | 39.2A | 22.6A |
| Power Output | 15hp(11KW) | 15hp(11KW) |
| Inverter power | 15hp(11KW) | 15hp(11KW) |
| Motor speed | 300-1600rpm | 300-1600rpm |
| Grinding width | 750mm | 750mm |
| Disc Dianeter | 250mm*3plate | 250mm*3plate |
| N.W | 390KG | 390KG |
| Water Tank | 30L | 30L |
| Dimension | 970*750*1050mm | 970*750*1050mm |
Features
Small size, for grinding and polishing small to medium area.
Total aluminum alloy gear box can be used for a longer life.
Hand can be adjusted 360 degree forwards and backwards.
Planetary four heads rotate on a large disk, with more efficiency
Contrast
gear box is smooth and clean exquisite craftwork
gear box is coars even the dregs are left by parts processing
Bearing is NSK, made in Japan, famous bearing name.
Chinese bearings, the quality is not as goodas that of Japan brand
Famous brand TTO seal made in Taiwan
No brand. notimported seal
Poly urethane rubber pads, the flexibility is adjusted many times,
for long life
Common material. theflexibility is not enough, easy to break
High strengthsteel. hard, solid
Common strengthsteel. even rust
High grade gear hobbin high-accuration
Not high grade gear hobbing,not high-accuration
Closer Look
Production Flow
Company introduction
Changsha Honway Machinery Co., Ltd is the Professional manufacturer
for floor scarifying & grinding & polishing machine in China.
1, Well equipped facilities for mechanical process.
2, Strict quality control throughout the stages of production.
3, A team of experienced technicians and workers.
4, All products are CE certified, comply with international
standard.
5, Covering a production area of 1000 square meter.
After Sell Service
- One year of warranty for machine.
- Honway always store the spare parts of old models, in case that the
machine needs repair in future.
- The spare parts can be sent out immediately at any time, delivered
by DHL.
- Honway will service you and your machines for years.
- All gear boxes are tested 48 hours before it leaves factory.
- If the customers visit our factory, we could provide the training
lessons.
- We always supply the spare parts for all the old models.
FAQ
Q: If your machine can be customized?
A: Yes, we can design and produce according to client’s requirements.
Q: What is your payment method?
A: 100% or 50% T/T advance, the balance should be paid before
shipment. (for old customers, we could discuss again)
Q: How about your delivery time?
A: 7~20 days (according to the order quantity)
