Concrete Scarifier Machine With 6-Point Scarifying Asphalt Milling
Cutter
Floor scarifier, Scarifiers, also called floor planers or milling
machines, remove concrete or asphalt faster and more aggressively
than grinders. HWS200, equipped with gasoline engine(original
Honda), or electrical motor 5.5kw (only for 380v, three phrase),
working width 200mm, working depth from 1-5mm (vary according to
the floor hardness)
Parameters:
| Model | HWS200 | HWS200E |
| Power OPtion | 9HP Honda Engine | 5.5KW Motor for 380V,3P |
| Working Width | 200mm | 200mm |
| Working Depth | 1-3mm | 1-3mm |
| Drum Rotation | Down cut(clockwise) | Down cut(clockwise) |
| Drum Assembly | Changeable | Changeable |
| Depth Control | Yes | Yes |
| Num of Shaft | 6pcs | 6pcs |
| Num of Cutter | 78pcs | 78pcs |
| Machine Weight | 105KG | 120KG |
| Packing Size | 1100*530*970mm | 1100*530*970mm |
| Walking Way | Push model | Push model
|
Application:
Removing heavy floor tile mastics, rubbery elastomeric or epoxy
materials
Level uneven surfaces and trip hazards.
Create the profile on the concrete floor.
Remove glue, oil, contaminants, mill scale and rust;
Features
HONDA gasoline engine assurance superior performance
Adjusting the removal depth easily with the handle wheel
Shafts are thicker than the average shafts in the market
Change the drum assembly in a few minutes
Front mounting lifting handle for easy transportation
Product Details
1, Good power source: original 9 HP Honda engine, air cooled 4
cycle the coiling inside motor is made of 100% copper. Good engine
andmotor guarantee the powerful driving force
4, Good quality bearing and bearing assembly.
Closer Look
Production Flow
Company introduction
Changsha Honway Machinery Co., Ltd is the Professional manufacturer
for floor scarifying & grinding & polishing machine in China. Our
company is well equipped with CNC machine for mechanical treatment
and gear hobbing machines for gear processing. We are proud of
having a team of experienced technicians and workers. All of the
products are CE certified and comply with international standard.
The products are already exported to 20 countries and got the good
reputation.
After Sell Service
1. One year of warranty for machine.
2. In the warranty period, the spare parts are sent by DHL, which
is paid by Honway Company.
3. Out of warranty period, the spare parts are sent by DHL, which
is paid by customer.
4. Honway always store the spare parts of old models, in case that
the machine needs repair in future.
5. Our strong R&D department offers technology support within 8
hours.
6. Topwell care service will follow you and your machine for years.
FAQ
Q:What is the working depth and working width of HWS200?
A: The working depth is 0-5mm, which also depends on the floor
condition. The working width is 200mm.
Q: As the cutters on the drum are 78pcs, is it enough for milling
floor?
A: Usually it is enough, most of our customers use 78pcs; If you
think it is not enough, we could add to 96pcs.
Q: What is the lifetime of the TCT cutters?
A: To be honest, it is hard to give a data of lifetime. It is because
the floor condition varies different.
